BOE 15.6 inch NT156FHM-N61-V8.0F HD IPS LCD Screen Notebook PC 1

BOE 15.6 inch NT156FHM-N61-V8.0F HD IPS LCD Screen Notebook PC 2

BOE 15.6 inch NT156FHM-N61-V8.0F HD IPS LCD Screen Notebook PC 3

BOE 15.6 inch NT156FHM-N61-V8.0F HD IPS LCD Screen Notebook PC

Display Screen 1920*1080 EDP display Anti-glare screen

The NT156FHM-N61 V8.0 TFT-LCD module by BOE delivers 1920×1080 Full HD resolution with 262K colors (6-bit depth) and a 45% color gamut, ensuring vibrant visuals. Its 220 cd/m² brightness and 500:1 contrast ratio provide sharp clarity, while the 12ms response time minimizes motion blur. Designed for efficiency, it features low power consumption (3.12W max) and a 15,000-hour LED lifespan. The module supports eDP interface, integrates an EDID chip, and offers PWM dimming (200Hz–10kHz). Its slim profile (3.2mm thickness) and RoHS/Halogen-free compliance make it eco-friendly. Ideal for industrial and consumer displays, it combines reliability with wide viewing angles (H: ±45°, V: ±40°) and anti-glare coating.

Screen size:

15.6"

Place of origin:

China, Guangdong

Model number:

NT156FHM-N61-V8.0

Resolution:

1920*1080

Delivery time:

Within 15 days

Warranty:

1 year

Inquiry

download

NT156FHM-N61 V8

Write a Review

Product Introduction

The NT156FHM-N61 V8.0 is a 15.6-inch LCD module with 1920×1080 resolution, optimized for low-voltage operation (3.3V) and energy efficiency. It features single LED backlight (bottom-mounted), 5-point luminance uniformity (ΔY5 ≥80%), and data-enable signal mode. The on-board LED driver supports 5–21V input, while its compact design (350.96×216.75mm) suits space-constrained applications. With cross-talk ≤4% and IPEX connectors, it ensures stable performance in embedded systems, medical devices, and portable displays.

Category	Parameter	Value
Display	Resolution	1920×1080 (RGB stripe)
	Active Area	344.16×193.59mm
	Color Depth	262K (6-bit)
Optical	Brightness (Typ.)	220 cd/m²
	Contrast Ratio	500:1
	Viewing Angle (H/V)	±45°/±40° (CR>10)
Electrical	Power Supply (VDD)	3.3V ±10%
	Power Consumption (Typ.)	3.12W (Total)
Backlight	LED Lifetime	15,000 hours (20.02mA)
	PWM Dimming Range	200Hz–10kHz, 1–100% duty
Mechanical	Dimensions (W×H×D)	350.96×216.75×3.2mm
	Weight	≤360g

Application Scenario

Experience crisp Full HD visuals with BOE’s NT156FHM-N61 V8.0—slim, energy-efficient, and built for durability. Perfect for industrial and portable displays!

Notebook PCs

Primary display for ultrabooks and business laptops.

Multimedia devices:

Supports dynamic content with 30ms response time

Embedded Systems:

Reliable displays for industrial/commercial tools.

Industrial Displays:

Durable AG coating resists scratches in harsh environments.

Frequently Asked Questions

What is the operating temperature range?

0°C to +50°C (non-condensing).

Does it support PWM dimming?

Yes, 200Hz–10kHz frequency with 0.4% resolution at 1kHz.

Is the module RoHS compliant?

Yes, it meets RoHS and Halogen-free standards.

What connectors are used?

STM MSAK24025P30 (signal) and IPEX 20454-030T (housing).

How is luminance uniformity measured?

ΔY5 (5-point) ≥80%, ΔY13 (13-point) ≥60%.

Can the backlight voltage exceed 21V?

No, absolute max is 21V to avoid damage.
