BESTAR can provide OEM&ODM services for all kinds of display touch screen SKD kits

BOE 15.6 inch PV156FHM-N30 350Nits FHD IPS LCD Screen 1

BOE 15.6 inch PV156FHM-N30 350Nits FHD IPS LCD Screen 2

BOE 15.6 inch PV156FHM-N30 350Nits FHD IPS LCD Screen 3

BOE 15.6 inch PV156FHM-N30 350Nits FHD IPS LCD Screen

Display Screen 1920*1080 EDP Notebook PC display Anti-glare screen

The PV156FHM-N20 is a high-performance 15.6-inch TFT LCD module featuring FHD resolution (1920×1080 pixels) with RGB vertical stripe pixel arrangement, delivering 262K colors for vibrant visuals. With a typical brightness of 320 cd/m² (up to 400 cd/m² max) and an 800:1 contrast ratio, it ensures sharp and bright displays. The module supports eDP 1.2 interface, ensuring seamless connectivity. Its ultra-thin design (3.2mm max thickness) and low power consumption (6.3W max) make it ideal for portable devices. The 85° wide viewing angle (horizontal/vertical) and 30ms response time enhance usability from multiple angles. Built with anti-glare (AG) coating and 3H hardness surface, it resists scratches and reflections. Designed for notebook PCs, it combines durability, energy efficiency, and high color accuracy.

Screen size:

15.6"

Place of origin:

China, Guangdong

Model number:

PV156FHM-N30

Resolution:

1920*1080

Delivery time:

Within 15 days

Warranty:

1 year

Inquiry

download

B8 PV156FHM-N30 Product Specification _ Rev

Write a Review

Product Introduction

The PV156FHM-N30 is a 15.6-inch TFT-LCD module with 1920×1080 resolution, offering 16.2M colors and 45% color gamut. It features a 350 cd/m² luminance, 1000:1 contrast ratio, and wide viewing angles (85° horizontal/vertical). The eDP 1.2 interface ensures high-speed data transmission, while the anti-glare surface reduces reflections. Designed for notebooks, it includes an integrated LED backlight (60-LED array) and 3H-hardness polarizer for scratch resistance. With low power consumption and compact dimensions (350.66×205.24 mm), it’s a versatile choice for high-quality displays.

BOE 15.6 inch PV156FHM-N30 350Nits FHD IPS LCD Screen 5

Parameter	Specification
Model	PV156FHM-N30
Screen Size	15.6 inches
Resolution	1920×1080 (Full-HD)
Brightness	350 cd/m² (typ)
Contrast Ratio	1000:1
Color Gamut	45%
Viewing Angles	85° (H/V)
Interface	eDP 1.2
Power Consumption	5.495W (max)
Backlight Lifespan	50,000 hours
Dimensions	350.66×205.24×5.8 mm (with PCB)

Application Scenario

Experience crisp Full-HD clarity with the PV156FHM-N30—boasting 350 cd/m² brightness, wide viewing angles, and 45% color gamut. Perfect for notebooks, its eDP 1.2 interface and anti-glare screen ensure seamless performance. Reliable, energy-efficient, and built to last.

Notebook PCs

Primary display for ultrabooks and business laptops.

Multimedia devices:

Supports dynamic content with 30ms response time

Embedded Systems:

Reliable displays for industrial/commercial tools.

Industrial Displays:

Durable AG coating resists scratches in harsh environments.

Frequently Asked Questions

What is the operating temperature range?

0°C to 50°C (non-condensing).

Does it support touch functionality?

No, this is a standard LCD module without touch.

What’s the response time?

20ms (typ), ensuring smooth motion handling.

Is the backlight user-replaceable?

No, the LED backlight is integrated and not user-serviceable.

What’s the warranty period?

Refer to BOE’s official warranty policy (not specified in the document).

Can it be used outdoors?

Limited outdoor use due to 350 cd/m² brightness; direct sunlight may reduce visibility.
