Outdoor LCD Screen 10.1 Inch BSD101WUM-N80-800CD 1920*1200 1

Outdoor LCD Screen 10.1 Inch BSD101WUM-N80-800CD 1920*1200 2

Outdoor LCD Screen 10.1 Inch BSD101WUM-N80-800CD 1920*1200

High Brightness WUXGA 1000nits TFT Display Module

The BSD101WUM-N80-800CD is a 10.1-inch industrial-grade TFT-LCD module featuring a 1920×1200 (WUXGA) resolution, 800 cd/m² brightness (customizable), and 900:1 contrast ratio. With an active display area of 216.8×135.5 mm and slim profile (2.4mm panel thickness), it employs LVDS interface and wide-temperature operation (-20°C to +70°C). Designed for harsh environments, its high brightness, 72% NTSC color gamut, and 80/80/80/80 viewing angle make it ideal for industrial control systems, outdoor displays, and specialized equipment requiring reliable visual performance

Bildschirmgröße:

10.1"

Herkunftsort:

China, Guangdong

Modellnummer:

BSD101WUM-N80-800CD

Auflösung:

1920*1200

Liefer frist:

Within 15 days

Garantie:

1 year

Anfrage

Eine Rezension schreiben

Introducere de produs

The BSD101WUM-N80 from Shenzhen Bestar is a rugged 10.1-inch TFT-LCM with WUXGA resolution (1920×1200), designed for demanding environments. It delivers 800 cd/m² brightness (adjustable), 900:1 contrast, and 72% NTSC color gamut. Featuring a slim 2.4mm panel thickness, LVDS interface, and wide operating temperature (-20°C to +70°C), it ensures clarity in extreme conditions. Its 80° viewing angle (CR>10) and 35ms response time suit industrial HMI, outdoor kiosks, medical devices, and transportation systems where reliability and visibility are critical. The module supports 16.7M colors and complies with industrial durability standards

Numele produsului	10.1” TFT Outdoor Use LCD SCreen
Numărul de model	BSD101WUM-N80-800CD
Rezoluţie	1920(H)×1200(V)
Zona activă	216.8064(H)*135.504(V) mm
Dimensiunea conturului	229.2149.84.5 mm
Luminanță	800 cd/m² (Typ.)
Unghi de vizualizare	80/80/80/80 (tip.) (CR≥10)
Culori afișate	16,7 M(8 biți), 72% NTSC
Timp de răspuns	25 (Tip.)(Tr/Td) ms
Raport de contrast	900:1 (Typ.)
Temperatura de operare	-20 ~ 70 °C
Temperatura de depozitare	-30 ~ 80 °C
Suport personalizare	Panou tactil, cabluri pentru ecran, placă AD, placă principală, carcasă, etc.

afișarea produsului

Outdoor LCD Screen 10.1 Inch BSD101WUM-N80-800CD 1920*1200 4

10.1 Inch Outdoor TFT LCD

1920x1200,WUGA

How to connect

Outdoor LCD Screen 10.1 Inch BSD101WUM-N80-800CD 1920*1200 6

Ultra-Bright 800cd/m² WUXGA Display for Harsh Environments: Industrial-Grade Clarity, Built to Endure.

Outdoor LCD Screen 10.1 Inch BSD101WUM-N80-800CD 1920*1200 7

DISPLAY TOUCH PANEL KIT

Suport personalizare

faq for BSD101WUM-N80 TFT-LCM Module

What are the key specifications of the BSD101WUM-N80?

This 10.1-inch TFT-LCM features a 1920×1200 (WUXGA) resolution, 800 cd/m² brightness (customizable), 900:1 contrast ratio, and 72% NTSC color gamut. It operates at 3.3V power with LVDS interface, supports -20°C to +70°C temperatures, and has a slim 2.4mm panel thickness.

What interface does this module use?

It utilizes a 45-pin LVDS connector (FH34SRJ-45S-0.5SH or equivalent) for data transmission, compatible with industrial control systems. No additional signal converters are required for standard applications.

Is this display suitable for outdoor/industrial use?

Da. With 800-nit brightness, wide operating temperature range, and 80° viewing angles (CR>10), it is designed for harsh environments like outdoor kiosks, medical devices, and industrial HMIs.

Ce produse putem oferi?

Vă putem oferi ecran LCD, panou tactil, cabluri de ecran, placă AD, placă de bază și monitor personalizat. De asemenea, sprijinim serviciul ODM/OEM. Putem personaliza lungimea cablului ecranului, dimensiunea conturului panoului tactil și funcția plăcii AD în funcție de scenariul dvs. de utilizare.

Când puteți livra marfa?

Acesta este un produs de uz medical și poate fi livrat de obicei în 15 zile (în funcție de cantitatea comenzii).
