BOE 10.1" WUXGA TFT LCD Display Panel 500nits

The EV101WUM-N20 is a 10.1-inch Transmissive TFT LCD Module designed for industrial applications. With a WUXGA resolution (1920×1200) and 16.7 million colors, it delivers crisp, vibrant visuals. Key features include an IPS panel for wide viewing angles (85°/85°/85°/85°), high contrast ratio (1000:1), and 450–500 cd/m² brightness for clear visibility in diverse environments. Powered by an LVDS interface and 8-bit color depth, it supports smooth performance at 60Hz. Engineered with LED backlighting and AG25 anti-glare coating, it ensures excellent readability and durability. Rated for -20°C to +70°C operation, this module boasts robust reliability through thermal shock and humidity testing. Its compact design (228.3×149×2.5mm) and lightweight (120g) make it ideal for space-constrained setups. The EV101WUM-N20 prioritizes longevity with optimized power consumption (1.08W) and extended lifespan, ensuring reliable operation in demanding settings.

Screen size:

10.1"

Place of origin:

China, Guangdong

Model number:

EV101WUM-N20

Resolution:

1920*1200,WUXGA

Delivery time:

Within 15 days

Warranty:

1 year

Inquiry

download

BESTAR-101-EV101WUM-N20_SPEC (7S7P_500亮度228

Write a Review

Product Brief

BOE EV101WUM-N20 10.1-inch TFT LCD Module

A rugged, high-resolution display for industrial applications. Features 1920×1200 IPS panel, 16.7M colors, 1000:1 contrast, 450–500 cd/m² brightness, and wide 85° viewing angles. Engineered for extreme temperatures (-20°C to +70°C), with LED backlighting, AG25 anti-glare coating, and LVDS interface. Lightweight (120g) and energy-efficient (1.08W), it ensures reliable performance in harsh environments. Ideal for medical devices, transportation, and automation systems.

Product Name	10.1” TFT Outdoor Use LCD SCreen
Model Number	EV101WUM-N20
Resolution	1920(H)×1200(V)
Active Area	216.8064(H)*135.504(V) mm
Outline Size	229.2149.84.5 mm
Luminance	500 cd/m² (Typ.)
Viewing Angle	80/80/80/80(typ.) (CR≥10)
Display Colors	16.7M(8bit ) ,72%NTSC
Response Time	25 (Typ.)(Tr/Td) ms
Contrast Ratio	900:1 (Typ.)
Operating Temperature	-20 ~ 70 °C
Storage Temperature	-30 ~ 80 °C
Support Customization	Touch panel,screen cables, AD board, Main board,casing, ect.

product display

How to connect

TFT LCD Module BOE 10.1 Inch EV101WUM-N20 WUXGA 1920x1200 Semi-finished Products 8

500cd/m² WUXGA Display for Harsh Environments: Industrial-Grade Clarity

Why Choose This Display?

Maximize Visibility & Durability with the EV101WUM-N20! High-res 10.1-inch TFT LCD for rugged industrial use. Wide viewing angles, 16.7M colors, and LED backlighting ensure peak performance. Engineered for reliability in extreme conditions. Upgrade your displays today!

TFT LCD Module BOE 10.1 Inch EV101WUM-N20 WUXGA 1920x1200 Semi-finished Products 10

Abundant Stock, No Supply Worries

We maintain large inventory levels, ensuring stable supply with zero risk of discontinuation.

TFT LCD Module BOE 10.1 Inch EV101WUM-N20 WUXGA 1920x1200 Semi-finished Products 11

Authorized Distributor, Factory Pricing

As an authorized primary agent, we offer you the most competitive prices straight from the source factory.

Fully Customizable Display Touch Solutions

Tailor brightness levels, touchscreen aesthetics, and driver board functionality to perfectly match your requirements.

OptionalAC&DCTypeIISPD&SPDfailurealarm-282

12-Month Warranty + Lifetime Support

Enjoy a 12-month warranty plus lifetime online technical assistance—your peace of mind is our priority.

Application Scenario

Our products, when paired with various touchscreens, cabling, driver boards, or mainboards, can be applied across a wide range of fields, providing customers with one-stop solutions.

Industrial Automation

Control panels, machinery interfaces, and monitoring systems.

Medical Equipment

Hospital monitors, diagnostic devices, and lab instruments.

Retail & Signage

Digital menus, information kiosks, and interactive displays.

Smart Devices:

Embedded screens for IoT devices, smart meters, and home appliances.

faq for EV101WUM-N20 TFT-LCM Module

What is the maximum brightness of the EV101WUM-N20?

The typical brightness is 450–500 cd/m², ensuring optimal visibility even in well-lit environments.

Does it support wide temperature ranges?

Yes, it operates reliably from -20°C to +70°C and withstands storage up to 80°C.

Is the EV101WUM-N20 resistant to vibrations/shocks?

Yes, it passes IEC 60068-2-6/29 vibration/shock tests, suitable for rugged environments.

Can the display be viewed from all angles?

With an 85°/85°/85°/85° viewing angle, it maintains clarity vertically and horizontally.

What is the warranty period?

Standard warranty covers 12 months, extendable based on usage agreements.

Is the module RoHS compliant?

Yes, it adheres to environmental standards, ensuring safety and sustainability.
