Display Module Tester PG325 Series for LVDS/eDP/RGB/MIPI+OLED LCD Screen Use 1

Display Module Tester PG325 Series for LVDS/eDP/RGB/MIPI+OLED LCD Screen Use 2

Display Module Tester PG325 Series for LVDS/eDP/RGB/MIPI+OLED LCD Screen Use 3

Display Module Tester PG325 Series for LVDS/eDP/RGB/MIPI+OLED LCD Screen Use 4

Display Module Tester PG325 Series for LVDS/eDP/RGB/MIPI+OLED LCD Screen Use

Display Analyzer OLED Testing Tool Flexible Display Validation Platform

The PG325 Series Display Module Tester is a versatile diagnostic tool designed for comprehensive testing of small to medium-sized display panels. Key models include the PG325E (LVDS/eDP), PG325M (MIPI), PG325P (MIPI+OLED), and PG325R (RGB-TTL), supporting resolutions up to 2560x1440 (eDP) and 1920x1200 (MIPI/LVDS/RGB). It features programmable power supplies (VDD/VBL/VLED) with precision control (0.1V step, 5% accuracy) and multi-protection mechanisms (OCP/OVP/UCP/SCP). The integrated high-precision power monitoring displays real-time voltage/current data. Supported interfaces include MIPI DSI v1.02 (1–4 lanes, 1.0Gbps/lane), eDP 1.4 (1–4 lanes, 2.7Gbps/lane), RGB TTL, and LVDS. Advanced functionalities include OTP burning, customizable timing/pattern editing, cloud-based test configuration downloads, and touch-screen driver debugging support (I2C/SPI, 5-point touch). With its modular design, open-source firmware, and user-friendly GUI, this tester ensures efficient validation for R&D, production, and quality assurance in industries like consumer electronics and automotive displays.

Screen size:

0.96-55"

Place of origin:

China,Shenzhen

Model number:

PG325

Resolution:

Up to 2560x1440 (eDP), 1920x1200 (MIPI/LVDS), 1366x768 (RGB)

Delivery time:

Within 15 days

Warranty:

12 Months

Inquiry

Write a Review

Product Brief

PG325 Series Display Module Tester

The PG325 Series Display Tester offers a unified platform for rapid validation of display modules. Equipped with MIPI, eDP, RGB, and LVDS interfaces, it supports resolutions from 1366x768 to 2560x1440 across various panel types (TFT, OLED, etc.). Key features include programmable power outputs (VDD/VBL/VLED), precise timing control, and automated EDID/Timing detection. Users can edit MIPI initialization codes, import custom test patterns (JPG/PNG/BMP), and leverage cloud-hosted configurations. The built-in 2.4” touchscreen and microSD slot enable offline operation, while USB connectivity simplifies file transfers. Engineered for reliability, it includes overvoltage/current protection and supports 5-point touch calibration. Ideal for engineers requiring a cost-effective, customizable solution for display module prototyping and mass-production testing.

Related Parameters

Parameter	Specification
Display Interfaces	- MIPI DSI v1.02 (1–4 lanes, 1.0Gbps/lane) - eDP 1.4 (1–4 lanes, 2.7Gbps/lane) - RGB TTL (85MHz max) - LVDS (1/2 links, 85MHz max)
Resolution Support	Up to 2560x1440 (eDP), 1920x1200 (MIPI/LVDS), 1366x768 (RGB)
Color Depth	6/8-bit for all interfaces
Power Outputs	- VDD/VBL: 3–12V/1.5A (15W max) - VLED: 20–400mA (5W max) - TFT/OLED supplies (VSP/VSN/AVDD/ELVDD/etc.)
Protection Features	OCP/OVP/UCP/SCP for all power channels
Software Capabilities	Cloud-based test profiles, MIPI code editor, touch-screen debugging (I2C/SPI), timing/pattern automation
Connectivity	USB 2.0 (480Mbps), microSD (64GB), system debug port
Environmental	Operating Temp: 10–40°C, Humidity: 20–70% RH

Why Choose This Product?

Precision-Driven Display Testing. One Platform, Endless Possibilities – Validate Faster, Innovate Smarter.

Display Module Tester PG325 Series for LVDS/eDP/RGB/MIPI+OLED LCD Screen Use 6

Abundant Stock, No Supply Worries

We maintain large inventory levels, ensuring stable supply with zero risk of discontinuation.

Display Module Tester PG325 Series for LVDS/eDP/RGB/MIPI+OLED LCD Screen Use 7

Authorized Distributor, Factory Pricing

As an authorized primary agent, we offer you the most competitive prices straight from the source factory.

Fully Customizable Display Touch Solutions

Tailor brightness levels, touchscreen aesthetics, and driver board functionality to perfectly match your requirements.

OptionalAC&DCTypeIISPD&SPDfailurealarm-282

12-Month Warranty + Lifetime Support

Enjoy a 12-month warranty plus lifetime online technical assistance—your peace of mind is our priority.

Application Scenario

R&D Validation

Testing display modules for smart devices (phones, tablets, laptops) and automotive systems.

Production Lines

QA checks for OLED/TFT panels, eDP/HDMI displays, and RGB-TTL interfaces.

Touch Integration

Debugging I2C/SPI touch controllers during screen integration.

Customization

Prototyping with user-defined timing patterns and power sequences.

Education Labs

Teaching display interface protocols and testing methodologies.

Frequently Asked Questions

Does the PG325 support 4K resolution testing?

No. The maximum supported resolution is 2560x1440 (eDP) or 1920x1200 (MIPI/LVDS/RGB).

Can I program custom power sequences for TFT/OLED panels?

Yes. Users can configure voltage/current parameters (e.g., VGH/VGL for TFT, ELVDD/ELVSS for OLED) with step-by-step precision.

Is cloud integration mandatory for operation?

No. While cloud downloads provide pre-built test profiles, all functions (timing/pattern editing, code generation) are accessible offline via USB/microSD.

What touch-screen protocols are compatible?

The tester supports I2C and SPI interfaces for up to 5-point touch calibration and driver debugging.

Can I import custom test images?

Yes. JPG/PNG/BMP files can be imported directly into the pattern editor for playback during testing.

How many power channels does the PG325 have?

Up to 8 programmable channels (VDD/VBL/VLED, TFT/OLED supplies, VDDIO/TPVDD), each with independent settings and protection.
